Wofix Chipboard Screws Wood Pozidrive
The screws are ideally suited for the professional user. Pre-countersinking is no longer necessary. Pre-drilling is unnecessary for practically all types of wood. Lower insertion torque because of using a special screw thread. Less force needed thanks to special cut point, but high pull-out resistance is guaranteed.
- flat head
- galvanised
- extra deep bit groove and perfect fit with Wofix Bits
- special cutting point
- serrated screw thread
- SHR Quality mark and included in SKH Publication 98-08 (without pre-drilling into burglar-resistant façade elements)
Type
Wood
Fitting
Hinge
Turn/Tilt Fitting
Model
Universally usable, cutter faces under the head, shaft ribs (with partial Ø 4,5 and higher thread)
Specially for hinges and locks with a smooth head
Specially for 89x89 hinges, fits perfectly with 8 mm Ø smooth head
Specially for turn/tilt fittings, fits perfectly with 7 mm Ø smooth head
Thread type
Fine
Coarse
Screwing is similar to conventional thread
Screwing is faster than with normal thread (more screws per battery charge)
-
-
Article Dimensions(ØxL/dl)mm Type Thread type Implementation PZ no. Unit Outer box Pallet 0341002 3.0 x 12 Wood Fine Full thread PZ 1 200 15.200 364.800 0341003 3.0 x 16 Wood Fine Full thread PZ 1 200 15.200 364.800 0341004 3.0 x 20 Wood Fine Full thread PZ 1 200 15.200 364.800 0341005 3.0 x 25 Wood Fine Full thread PZ 1 200 15.200 364.800 0341006 3.0 x 30 Wood Fine Full thread PZ 1 200 15.200 364.800 0341007 3.0 x 35 Wood Fine Full thread PZ 1 200 9.600 230.400 0341008 3.0 x 40 Wood Fine Full thread PZ 1 200 9.600 230.400 0341009 3.0 x 45 Wood Fine Full thread PZ 1 200 6.400 135.600 0341010 3.5 x 12 Wood Fine Full thread PZ 2 200 15.200 364.800 0341011 3.5 x 16 Wood Fine Full thread PZ 2 200 15.200 364.800 0341012 3.5 x 20 Wood Fine Full thread PZ 2 200 15.200 364.800 0341013 3.5 x 25 Wood Fine Full thread PZ 2 200 15.200 364.800 0341014 3.5 x 30 Wood Fine Full thread PZ 2 200 9.600 230.400 0341015 3.5 x 35 Wood Fine Full thread PZ 2 200 9.600 230.400 0341016 3.5 x 40 Wood Fine Full thread PZ 2 200 6.400 153.600 0341017 3.5 x 45 Wood Fine Full thread PZ 2 200 6.400 153.600 0341018 3.5 x 50 Wood Fine Full thread PZ 2 200 6.400 153.600 0341020 4.0 x 16 Wood Fine Full thread PZ 2 200 15.200 364.800 0341091 4.0 x 16 Fitting/Wood Fine Full thread PZ 2 200 15.200 364.800 0341021 4.0 x 20 Wood Fine Full thread PZ 2 200 15.200 364.800 0341092 4.0 x 20 Fitting/Wood Fine Full thread PZ 2 200 15.200 364.800 0341022 4.0 x 25 Wood Fine Full thread PZ 2 200 15.200 364.800 0341093 4.0 x 25 Fitting/Wood Fine Full thread PZ 2 200 15.200 364.800 0341023 4.0 x 30 Wood Fine Full thread PZ 2 200 9.600 230.400 0341094 4.0 x 30 Fitting/Wood Fine Full thread PZ 2 200 9.600 230.400 0341024 4.0 x 35 Wood Fine Full thread PZ 2 200 9.600 230.400 0341095 4.0 x 35 Fitting/Wood Fine Full thread PZ 2 200 9.600 230.400 0341025 4.0 x 40 Wood Fine Full thread PZ 2 200 6.400 153.600 0341035 4.0 x 40 Wood Coarse Full thread PZ 2 200 6.400 153.600 0341041 4.0 x 40 Fitting/Wood Coarse Full thread PZ 2 200 6.400 153.600 0341026 4.0 x 45 Wood Fine Full thread PZ 2 200 6.400 153.600 0341036 4.0 x 45 Wood Coarse Full thread PZ 2 200 6.400 153.600 0341096 4.0 x 45 Fitting/Wood Coarse Full thread PZ 2 200 6.400 153.600 0341027 4.0 x 50 Wood Fine Full thread PZ 2 200 6.400 153.600 0341037 4.0 x 50 Wood Coarse Full thread PZ 2 200 6.400 153.600 0341097 4.0 x 50 Fitting/Wood Coarse Full thread PZ 2 200 6.400 153.600 0341028 4.0 x 55 Wood Fine Full thread PZ 2 200 4.800 115.200 0341038 4.0 x 55 Wood Coarse Full thread PZ 2 200 4.800 115.200 0341029 4.0 x 60 Wood Fine Full thread PZ 2 200 4.800 115.200 0341039 4.0 x 60 Wood Coarse Full thread PZ 2 200 4.800 115.200 0341030 4.0 x 70 Wood Fine Full thread PZ 2 200 3.200 76.800 0341040 4.0 x 70 Wood Coarse Full thread PZ 2 200 3.200 76.800 0341044 4.5 x 16 Wood Fine Full thread PZ 2 200 15.200 364.800 0341045 4.5 x 20 Wood Fine Full thread PZ 2 200 15.200 364.800 0341046 4.5 x 25 Wood Fine Full thread PZ 2 200 9.600 230.400 0341047 4.5 x 30 Wood Fine Full thread PZ 2 200 6.400 153.600 0341048 4.5 x 35 Wood Fine Full thread PZ 2 200 6.400 153.600 0341049 4.5 x 40 Wood Coarse Full thread PZ 2 200 6.400 153.600 0341098 4.5 x 40 Fitting/Wood Coarse Full thread PZ 2 200 6.400 153.600 0341050 4.5 x 45 Wood Coarse Full thread PZ 2 200 4.800 115.200 0341099 4.5 x 45 Fitting/Wood Coarse Full thread PZ 2 200 4.800 115.200 0341051 4.5 x 50 Wood Coarse Full thread PZ 2 200 4.800 115.200 0341052 4.5 x 60 Wood Coarse Full thread PZ 2 200 3.200 76.800 0341053 4.5 x 70/42 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341054 4.5 x 80/53 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341056 5.0 x 16 Wood Fine Full thread PZ 2 200 9.600 230.400 0341057 5.0 x 20 Wood Fine Full thread PZ 2 200 9.600 230.400 0341058 5.0 x 25 Wood Fine Full thread PZ 2 200 9.600 230.400 0341059 5.0 x 30 Wood Fine Full thread PZ 2 200 6.400 153.600 0341060 5.0 x 35 Wood Fine Full thread PZ 2 200 6.400 153.600 0341064 5.0 x 40 Wood Coarse Full thread PZ 2 200 4.800 115.200 0341065 5.0 x 50 Wood Coarse Full thread PZ 2 200 4.800 115.200 0341066 5.0 x 60 Wood Coarse Full thread PZ 2 200 3.200 76.800 0341067 5.0 x 70/42 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341068 5.0 x 80/53 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341069 5.0 x 90/59 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341070 5.0 x 100/66 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341071 5.0 x 110/73 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341072 5.0 x 120/73 Wood Coarse Partial thread PZ 2 200 3.200 76.800 0341076 6.0 x 40 Wood Coarse Full thread PZ 3 200 4.800 115.200 0341077 6.0 x 50 Wood Coarse Full thread PZ 3 200 3.200 76.800 0341078 6.0 x 60 Wood Coarse Full thread PZ 3 200 3.200 76.800 0341079 6.0 x 70 Wood Coarse Full thread PZ 3 200 2.400 57.600 0341080 6.0 x 80/53 Wood Coarse Partial thread PZ 3 200 2.400 57.600 0341081 6.0 x 90/59 Wood Coarse Partial thread PZ 3 200 2.400 57.600 0341082 6.0 x 100/66 Wood Coarse Partial thread PZ 3 100 1.600 38.400 0341083 6.0 x 110/73 Wood Coarse Partial thread PZ 3 100 1.600 38.400 0341084 6.0 x 120/73 Wood Coarse Partial thread PZ 3 100 1.600 38.400 0341085 6.0 x 130/73 Wood Coarse Partial thread PZ 3 100 1.200 28.800 0341086 6.0 x 140/73 Wood Coarse Partial thread PZ 3 100 1.200 28.800 0341087 6.0 x 150/73 Wood Coarse Partial thread PZ 3 100 1.200 28.800 0341088 6.0 x 160/73 Wood Coarse Partial thread PZ 3 100 1.200 28.800 0341089 6.0 x 180/73 Wood Coarse Partial thread PZ 3 100 800 19.200 0341090 6.0 x 200/73 Wood Coarse Partial thread PZ 3 100 800 19.200 0340941 4.0 x 40 7mm Head Turn/Tilt Fitting Fine Full thread PZ 2 200 6.400 153.600 0341042 4.5 x 40
8mm HeadHinge
89x89Coarse Full thread PZ 2 200 6.400 153.600
-
