Wofix Chipboard Screws Wood Torx
The screws are ideally suited for the professional user. Pre-countersinking is no longer necessary. Pre-drilling is unnecessary for practically all types of wood. Lower insertion torque because of usinga special screw thread. Less force needed thanks to the special cut point, but high pull-out resistance is guaranteed.
- flat head
- galvanised
- extra deep bit groove and perfect fit with Wofix Bits
- special cutting point
- serrated screw thread
- SHR Quality mark and included in SKH Publication 98-08 (without pre-drilling into burglar-resistant façade elements)
Type
Wood
Fitting
Hinge
Turn/Tilt Fitting
Implementation
Universally usable, cutter faces under the head, shaft ribs (with partial 4,5 Ø and higher thread)
Specially for hinges and locks with smooth head
Specially for 89x89 hinges, fits perfectly with 8 mm Ø smooth head
Specially for turn/tilt fittings, fits perfectly with 7 mm Ø smooth head
Thread type
Fine
Coarse
Screwing is similar to conventional thread
Screwing is faster than with normal thread (more screws per battery charge)
-
-
Article Dimensions(ØxL/dl)mm Type Thread type Implementation TX no. Unit Outer box Pallet 0341102 3.0 x 12 Wood Fine Full thread TX 10 200 15.200 364.800 0341103 3.0 x 16 Wood Fine Full thread TX 10 200 15.200 364.800 0341104 3.0 x 20 Wood Fine Full thread TX 10 200 15.200 364.800 0341105 3.0 x 25 Wood Fine Full thread TX 10 200 15.200 364.800 0341106 3.0 x 30 Wood Fine Full thread TX 10 200 15.200 364.800 0341206 3.0 x 30/18 Wood Fine Partial thread TX 10 200 15.200 364.800 0341107 3.0 x 35 Wood Fine Full thread TX 10 200 9.600 230.400 0341207 3.0 x 35/20 Wood Fine Partial thread TX 10 200 9.600 230.400 0341108 3.0 x 40 Wood Fine Full thread TX 10 200 9.600 230.400 0341109 3.0 x 45 Wood Fine Full thread TX 10 200 6.400 135.600 0341110 3.5 x 12 Wood Fine Full thread TX 15 200 15.200 364.800 0341111 3.5 x 16 Wood Fine Full thread TX 15 200 15.200 364.800 0341112 3.5 x 20 Wood Fine Full thread TX 15 200 15.200 364.800 0341113 3.5 x 25 Wood Fine Full thread TX 15 200 15.200 364.800 0341114 3.5 x 30 Wood Fine Full thread TX 15 200 9.600 230.400 0341214 3.5 x 30/18 Wood Fine Partial thread TX 15 200 9.600 230.400 0341115 3.5 x 35 Wood Fine Full thread TX 15 200 9.600 230.400 0341215 3.5 x 35/20 Wood Fine Partial thread TX 15 200 9.600 230.400 0341116 3.5 x 40 Wood Fine Full thread TX 15 200 6.400 153.600 0341216 3.5 x 40/24 Wood Fine Partial thread TX 15 200 6.400 153.600 0341117 3.5 x 45 Wood Fine Full thread TX 15 200 6.400 153.600 0341118 3.5 x 50 Wood Fine Full thread TX 15 200 6.400 153.600 0341120 4.0 x 16 Wood Fine Full thread TX 20 200 15.200 364.800 0341193 4.0 x 16 Fitting/Wood Fine Full thread TX 20 200 15.200 364.800 0341121 4.0 x 20 Wood Fine Full thread TX 20 200 15.200 364.800 0341194 4.0 x 20 Fitting/Wood Fine Full thread TX 20 200 15.200 364.800 0341122 4.0 x 25 Wood Fine Full thread TX 20 200 15.200 364.800 0341195 4.0 x 25 Fitting/Wood Fine Full thread TX 20 200 15.200 364.800 0341123 4.0 x 30 Wood Fine Full thread TX 20 200 9.600 230.400 0341223 4.0 x 30/18 Wood Fine Partial thread TX 20 200 9.600 230.400 0341196 4.0 x 30 Fitting/Wood Fine Full thread TX 20 200 9.600 230.400 0341124 4.0 x 35 Wood Fine Full thread TX 20 200 9.600 230.400 0341224 4.0 x 35/20 Wood Fine Partial thread TX 20 200 9.600 230.400 0341197 4.0 x 35 Fitting/Wood Fine Full thread TX 20 200 9.600 230.400 0341125 4.0 x 40 Wood Fine Full thread TX 20 200 6.400 153.600 0341225 4.0 x 40/24 Wood Fine Partial thread TX 20 200 6.400 153.600 0341135 4.0 x 40 Wood Coarse Full thread TX 20 200 6.400 153.600 0341141 4.0 x 40 Fitting/Wood Coarse Full thread TX 20 200 6.400 153.600 0341126 4.0 x 45 Wood Fine Full thread TX 20 200 6.400 153.600 0341226 4.0 x 45/27 Wood Fine Partial thread TX 20 200 6.400 153.600 0341136 4.0 x 45 Wood Coarse Full thread TX 20 200 6.400 153.600 0341198 4.0 x 45 Fitting/Wood Coarse Full thread TX 20 200 6.400 153.600 0341127 4.0 x 50 Wood Fine Full thread TX 20 200 6.400 153.600 0341227 4.0 x 50/30 Wood Fine Partial thread TX 20 200 6.400 153.600 0341137 4.0 x 50 Wood Coarse Full thread TX 20 200 6.400 153.600 0341199 4.0 x 50 Fitting/Wood Coarse Full thread TX 20 200 6.400 153.600 0341128 4.0 x 55 Wood Fine Full thread TX 20 200 4.800 115.200 0341138 4.0 x 55 Wood Coarse Full thread TX 20 200 4.800 115.200 0341129 4.0 x 60 Wood Fine Full thread TX 20 200 4.800 115.200 0341229 4.0 x 60/36 Wood Fine Partial thread TX 20 200 4.800 115.200 0341139 4.0 x 60 Wood Coarse Full thread TX 20 200 4.800 115.200 0341130 4.0 x 70 Wood Fine Full thread TX 20 200 3.200 76.800 0341230 4.0 x 70/42 Wood Fine Partial thread TX 20 200 3.200 76.800 0341140 4.0 x 70 Wood Coarse Full thread TX 20 200 3.200 76.800 0341144 4.5 x 16 Wood Fine Full thread TX 25 200 15.200 364.800 0341145 4.5 x 20 Wood Fine Full thread TX 25 200 15.200 364.800 0341146 4.5 x 25 Wood Fine Full thread TX 25 200 9.600 230.400 0341147 4.5 x 30 Wood Fine Full thread TX 25 200 6.400 153.600 0341148 4.5 x 35 Wood Fine Full thread TX 25 200 6.400 153.600 0341149 4.5 x 40 Wood Coarse Full thread TX 25 200 6.400 153.600 0341200 4.5 x 40 Fitting/Wood Coarse Full thread TX 25 200 6.400 153.600 0341150 4.5 x 45 Wood Coarse Full thread TX 25 200 4.800 115.200 0341201 4.5 x 45 Fitting/Wood Coarse Full thread TX 25 200 4.800 115.200 0341151 4.5 x 50 Wood Coarse Full thread TX 25 200 4.800 115.200 0341152 4.5 x 60 Wood Coarse Full thread TX 25 200 3.200 76.800 0341153 4.5 x 70/42 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341154 4.5 x 80/53 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341156 5.0 x 16 Wood Fine Full thread TX 25 200 9.600 230.400 0341157 5.0 x 20 Wood Fine Full thread TX 25 200 9.600 230.400 0341158 5.0 x 25 Wood Fine Full thread TX 25 200 9.600 230.400 0341159 5.0 x 30 Wood Fine Full thread TX 25 200 6.400 153.600 0341160 5.0 x 35 Wood Fine Full thread TX 25 200 6.400 153.600 0341164 5.0 x 40 Wood Coarse Full thread TX 25 200 4.800 115.200 0341165 5.0 x 50 Wood Coarse Full thread TX 25 200 4.800 115.200 0341166 5.0 x 60 Wood Coarse Full thread TX 25 200 3.200 76.800 0341167 5.0 x 70/42 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341168 5.0 x 80/53 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341169 5.0 x 90/59 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341170 5.0 x 100/66 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341171 5.0 x 110/73 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341172 5.0 x 120/73 Wood Coarse Partial thread TX 25 200 3.200 76.800 0341176 6.0 x 40 Wood Coarse Full thread TX 30 200 4.800 115.200 0341177 6.0 x 50 Wood Coarse Full thread TX 30 200 3.200 76.800 0341178 6.0 x 60 Wood Coarse Full thread TX 30 200 3.200 76.800 0341179 6.0 x 70 Wood Coarse Full thread TX 30 200 2.400 57.600 0341180 6.0 x 80/53 Wood Coarse Partial thread TX 30 200 2.400 57.600 0341181 6.0 x 90/59 Wood Coarse Partial thread TX 30 200 2.400 57.600 0341182 6.0 x 100/66 Wood Coarse Partial thread TX 30 100 1.600 38.400 0341183 6.0 x 110/73 Wood Coarse Partial thread TX 30 100 1.600 38.400 0341184 6.0 x 120/73 Wood Coarse Partial thread TX 30 100 1.600 38.400 0341185 6.0 x 130/73 Wood Coarse Partial thread TX 30 100 1.200 28.800 0341186 6.0 x 140/73 Wood Coarse Partial thread TX 30 100 1.200 28.800 0341187 6.0 x 150/73 Wood Coarse Partial thread TX 30 100 1.200 28.800 0341188 6.0 x 160/73 Wood Coarse Partial thread TX 30 100 1.200 28.800 0341189 6.0 x180/73 Wood Coarse Partial thread TX 30 100 800 19.200 0341190 6.0 x 200/73 Wood Coarse Partial thread TX 30 100 800 19.200 0341191 6.0 x 220/73 Wood Coarse Partial thread TX 30 100 800 19.200 0341192 6.0 x 240/73 Wood Coarse Partial thread TX 30 100 800 19.200 0341290 6.0 x 260/73 Wood Coarse Partial thread TX 30 100 800 19.200 0341291 6.0 x 280/73 Wood Coarse Partial thread TX 30 100 600 14.400 0341292 6.0 x 300/73 Wood Coarse Partial thread TX 30 100 600 14.400 0341241 4.0 x 40 7mm Head Turn/Tilt Fitting Fine Full thread TX 20 200 6.400 153.600 0341142 4.5 x 40
8mm HeadHinge
89x89Coarse Full thread TX 20 200 6.400 153.600
-
